    Z46
    Adaptation Project
    ask about the project
    Home project Z46

    Z46 mirror image

    concept
    concept
    concept
    concept
    mirror image
    Home project Z46

    IF YOU HAVE ANY QUESTIONS CALL US

    (718) 810-5358

    Mon - Fri: 8:00 - 19:00

    ask about the project
    Home project  - Dom dwurodzinny o dworkowym charakterze i tradycyjnej stylistyce. Oddzielne wejścia

    Ground 144,0 ft²

    34,3 ft²
    163,0 ft²
    347,5 ft²
    165,8 ft²
    23,9 ft²
    46,1 ft²
    49,7 ft²
    103,1 ft²
    125,5 ft²
    55,3 ft²
    235,0 ft²
    142,5 ft²
    58,2 ft²
    mirror
    Draw
    Click or touch on the image on the left to start the measure.
    Draw sketch on image and click save icon.
    Sketch has been sent.
    Home project  - Dom dwurodzinny o dworkowym charakterze i tradycyjnej stylistyce. Oddzielne wejścia

    Garret 97,7 / 149,7 ft²

    148,8 ft²
    112,7 ft² / 225,6 ft²
    163,4 ft² / 275,7 ft²
    151,7 ft² / 251,2 ft²
    165,4 ft² / 201,3 ft²
    236,8 ft² / 338,9 ft²
    34,3 ft² / 102,7 ft²
    38,2 ft² / 66,8 ft²
    49,2 ft²
    49,2 ft²
    mirror
    Draw
    Click or touch on the image on the left to start the measure.
    Draw sketch on image and click save icon.
    Sketch has been sent.
    Home project  - Dom dwurodzinny o dworkowym charakterze i tradycyjnej stylistyce. Oddzielne wejścia

    Minimal plot - dimensions, which must have a plot that house could be placed in accordance with the
    Minimal plot

    width
    24,39 ft
    length
    20,49 ft
    Dimensions of the front elevation
    Dimensions of the front elevation - the dimensions of the front façade of the building along with the retaining wall surfaces excluding windows and doors
    16,39 ft

    Area and dimensions

    Usable / net area
    241,7 / 293,7 ft²
    Usable: Area of all rooms except for the technical room, garage, utility room, attic. When sizes does not include plaster and wall coverings.
    Net area: This is the area of all rooms of the building measured at floor level, taking into account plaster and wall cladding. Does not diminish the floor area of variable height - eg. In the attic. To put it simply - so as to spread in all areas of the carpet on the floor.
    Living area
    184,7 ft²
    Living area: Is a surface contour of the exterior walls of the building. For building area is not included: the underground part of the building, ramp car, external stairs, porches, canopies over the entrances, galleries and all floor. But it takes into account eg. Conservatories or other elements of the build.
    Cubic
    698,79 ft³
    Cubic: The volume of the room, or floor area multiplied by the height of the floor. To calculate the volume of the assumed height measured from the floor - from the bottom floor or to the bottom of the flat roof.
    The height of the house
    8,53 ft
    The height of the house - height from ground level to the ridge or attic.
    The angle of inclination of the roof
    40°
    The angle of inclination of the roof - the angle of the roof to the ground.
    Roof area
    284,9 ft²
    Roof area - total roof area with the exception of roof windows.
    The height of a dwarf wall
    0,6 ft
    The height of a dwarf wall - wall additions were made at the rally (the top of the building), enhancing the roof in order to increase the usable space of the attic.
    Minimal plot
    24,39 x 20,49 ft


    Technology and construction

    Walls
    aerated concrete/ceramics/silicates
    Ceiling (ground floor)
    beam and block
    Roofing
    Metal tile/tile
    technology
    brick

    Project's construction is based on:

    • II Strefa wiatrowa
    • II Strefa śniegowa
    • I Strefa przemarzania gruntu
    • Budynek zaliczono do I-ej kategorii geotechnicznej.
    • Rodzaj gruntu, naprężenia dopuszczalne dla podłoża - przyjęto zgodnie z warunkami gruntowymi w obliczeniach statycznych (osobny aneks w ramach projektu typowego)

    Thermal insulation

    heating system
    gas
    heating system - Type of heating provided for the project
    Hot water installation
    gas
    Ventilation type
    mechaniczna
