Z321
131 ft²
Variants: 2
Comments: 37
$1 400
IF YOU HAVE ANY QUESTIONS CALL US
Usable / net area
Usable: Area of all rooms except for the technical room, garage, utility room, attic. When sizes does not include plaster and wall coverings.
Net area: This is the area of all rooms of the building measured at floor level, taking into account plaster and wall cladding. Does not diminish the floor area of variable height - eg. In the attic. To put it simply - so as to spread in all areas of the carpet on the floor.
Net area: This is the area of all rooms of the building measured at floor level, taking into account plaster and wall cladding. Does not diminish the floor area of variable height - eg. In the attic. To put it simply - so as to spread in all areas of the carpet on the floor.
130,6
/ 135,4
ft²
Living area
Living area: Is a surface contour of the exterior walls of the building. For building area is not included: the underground part of the building, ramp car, external stairs, porches, canopies over the entrances, galleries and all floor. But it takes into account eg. Conservatories or other elements of the build.
169,0 ft²
Cubic
Cubic: The volume of the room, or floor area multiplied by the height of the floor. To calculate the volume of the assumed height measured from the floor - from the bottom floor or to the bottom of the flat roof.
378,99 ft³
The height of the house
The height of the house - height from ground level to the ridge or attic.
6,17 ft
The angle of inclination of the roof
The angle of inclination of the roof
- the angle of the roof to the ground.
20°
Roof area
Roof area - total roof area with the exception of roof windows.
258,74 ft²
Minimal plot
22,76
x
21,26 ft
Ceiling (ground floor)
trusses
Roofing
shingle/plate/Metal tile/tile
technology
brick
Roof construction
prefabricated trusses
heating system
heating system - Type of heating provided for the project
gas, electrical cables
Hot water installation
gas, heat pump
Ventilation type
mechaniczna
Primary energy (Ep)
Primary energy (Ep) - the amount of energy extracted at source and needed to meet the demand for home heating, domestic hot water, air conditioning, mechanical ventilation.
66,49 kWh/ft²/year
Final energy (Ek)
Final energy (Ek) - the amount of energy that must be purchased to ogrzawania home, domestic hot water, mechanical ventilation, and air conditioning. More specifically, it is the energy per 1 m² per year.
50,06 kWh/ft²/year
Ground 130,6 / 135,4 ft²
Drawmirror image
Click or touch on the image on the left to start the measure.
42,2 ft²
Hall
3,9 ft²
Hol
12,0 ft²
130,9 ft²
Bathroom
3,0 ft²
159,8 ft²
Living room + dining room
39,9 ft²
123,9 ft²
Kitchen
8,3 ft²
123,9 ft²
195,0 ft²
Cabinet
14,9 ft²
80,4 ft²
Room
11,6 ft²
Room
11,4 ft²
32,7 ft²
Room
18,1 ft²
418,0 ft²
Bathroom
7,5 ft²
92,1 ft²
45,3 ft²
Utility room
4,8 ft²
Lot
Minimal plot
Minimal plot - dimensions, which must have a plot that house could be placed in accordance with the
width
22,76 ft
length
21,26 ft
Dimensions of the front elevation
Dimensions of the front elevation - the dimensions of the front façade of the building along with the retaining wall surfaces excluding windows and doors
14,76 ft
