Home project Zx152

Zx152 mirror image

brick
concept
project's availability 3 work days
$6 070
brick
concept
project's availability 3 work days
mirror image
$6 070
Home project Zx152
Home project Zx152
Home project Zx152
Home project Zx152

Talk to the architect who designed the house

(718) 810-5358

Mon - Fri: 8:00 - 19:00

ask about the project
Home project  - Piętrowy, nowoczesny dom o powierzchni 225m2 z płaskim dachem oraz dużym tarasem

Ground 1207,8 / 1681,3 ft²

Sień
38,2 ft²
Hol+schody
187,1 ft²
Winiarnia
48,6 ft²
Pralnia
55,1 ft²
Gabinet
159,7 ft²
Garderoba
42,0 ft²
Salon+jadalnia
495,9 ft²
Kuchnia
151,3 ft²
Siłownia
38,0 ft²
Pomieszczenie gospodarcze
85,4 ft²
Garaż
391,7 ft²
mirror
Draw

Click or touch on the image on the left to start the measure.
Draw sketch on image and click save icon.
Sketch has been sent.
Home project  - Piętrowy, nowoczesny dom o powierzchni 225m2 z płaskim dachem oraz dużym tarasem

Floor 1204,9 ft²

Garderoba
204,3 ft²
Pokój
162,8 ft²
Pokój
175,3 ft²
Pokój
184,1 ft²
Łazienka
126,2 ft²
Łazienka
74,8 ft²
Garderoba
81,6 ft²
Pokój
188,3 ft²
Garderoba
27,6 ft²
mirror
Draw

Click or touch on the image on the left to start the measure.
Draw sketch on image and click save icon.
Sketch has been sent.
Home project  - Piętrowy, nowoczesny dom o powierzchni 225m2 z płaskim dachem oraz dużym tarasem

Minimal plot - dimensions, which must have a plot that house could be placed in accordance with the
Minimal plot

width
78,77 ft
length
78,12 ft
Dimensions of the front elevation
Dimensions of the front elevation - the dimensions of the front façade of the building along with the retaining wall surfaces excluding windows and doors
55,81 ft

Area and dimensions

Usable / net
2412,7 / 2886,2 ft²
Usable: Area of all rooms except for the technical room, garage, utility room, attic. When sizes does not include plaster and wall coverings.
Net area: This is the area of all rooms of the building measured at floor level, taking into account plaster and wall cladding. Does not diminish the floor area of variable height - eg. In the attic. To put it simply - so as to spread in all areas of the carpet on the floor.
Living area
2459,8 ft²
Living area: Is a surface contour of the exterior walls of the building. For building area is not included: the underground part of the building, ramp car, external stairs, porches, canopies over the entrances, galleries and all floor. But it takes into account eg. Conservatories or other elements of the build.
Garage area
388,0 ft²
Cubic
27 910,2 ft³
Cubic: The volume of the room, or floor area multiplied by the height of the floor. To calculate the volume of the assumed height measured from the floor - from the bottom floor or to the bottom of the flat roof.
The height of the house
28,22 ft
The height of the house - height from ground level to the ridge or attic.
The angle of inclination of the roof
The angle of inclination of the roof - the angle of the roof to the ground.
Roof area
1 520,4 ft²
Roof area - total roof area with the exception of roof windows.
Minimal plot
78,77 x 78,12 ft


Technology and construction

Walls
aerated concrete, ceramics, silicates
Ceiling (ground floor)
reinforced concrete
Roof
foil, bituminous
technology
brick

Thermal insulation

heating system
solid fuel, ERV
heating system - Type of heating provided for the project
